उत्पाद विवरण
उत्पत्ति के प्लेस: चीन, गुआंगडोंग
ब्रांड नाम: YUSH
मॉडल संख्या: YS-A410
भुगतान और शिपिंग शर्तें
न्यूनतम आदेश मात्रा: 1
मूल्य: USD35000
प्रसव के समय: 20 कार्य दिवस
भुगतान शर्तें: एल/सी, डी/ए, डी/पी, टी/टी, वेस्टर्न यूनियन
आपूर्ति की क्षमता: 1000
वोल्टेज: |
220V |
शक्ति (डब्ल्यू): |
6KW |
वज़न: |
310 किग्रा |
आयाम (l*w*h): |
868*1033*1340 मिमी |
मॉडल संख्या: |
YS-A410 |
वोल्टेज: |
220V |
शक्ति (डब्ल्यू): |
6KW |
वज़न: |
310 किग्रा |
आयाम (l*w*h): |
868*1033*1340 मिमी |
मॉडल संख्या: |
YS-A410 |
| Voltage | 220V |
|---|---|
| Power | 6KW |
| Weight | 310KG |
| Dimensions (L×W×H) | 868 × 1033 × 1340mm |
| Model Number | YS-A410 |
| Inspection | Using multiple algorithms synthetically such as WIDM, Color Image contrast technology, Color extracting technology, similarity, two-value handling technology, OCR/OCV and so on |
|---|---|
| Camera | Colour camera: 20 μm (15μm for Optical) |
| Lamp-house | Ring RGB LED flash lamp-house |
| Image Processing Speed | 0201 Chip - <10ms Per-image Time - <170ms |
| Inspection Items |
Paste Printing Defects: Misaligned, overflow, insufficient, pasting open, stain Component Defects: Missing, misaligned, skewed, tombstone, billboard, overturned, reversed polarity, wrong, damaged Solder Defects: Overflow, insufficient, short solder, stain |
| Anti Static Measures | Anti-static electric outlet, anti-static wreath |
| PCB Size | 25 × 25 mm - 480 × 330mm (Can be customized) |
| Machine Dimensions | 868 × 1033 × 1340mm |
| Power Supply | AC220V ±10%, single phase 50/60HZ, power consumption 600W |
| Weight | ~310kg |
| PCB Thickness | 0.5mm-5mm |
| PCB Warp Tolerance | ± 2mm |
| Computer | CPU: Intel dual-core, Memory: 4G, Hard disk: 1T |
| Display | 22-inch TFT |
| Component Clearance | TOP <28mm, BOT <75mm |
| Characteristics | WDM, study OK template, automatically set template imaging, identify data and error numerical value |
| Working Environment | Temperature 10-40℃, humidity 30-80%RH |
