Shenzhen Stainless Steel Cutting Machine Wheel Made in China . CNC Laser Cutting Machine

उत्पाद विवरण

उत्पत्ति के प्लेस: जियांग्सू, चीन

ब्रांड नाम: YUSH

भुगतान और शिपिंग शर्तें

न्यूनतम आदेश मात्रा: 1 सेट

मूल्य: $31,000 / set

सबसे अच्छी कीमत पाएं

उत्पाद विवरण

उत्पाद का वर्णन

प्रमुखता देना:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Stainless Steel CNC Laser Cutting Machine, PCB Depaneling Machine with Warranty, China Made Laser Cutting Machine Wheel


वज़न:	3500 किलोग्राम	शक्ति:	10 किलोवाट
वोल्टेज:	220V, 380V	लेजर प्रकार:	यूवी
लेजर तरंगदैर्घ्य:	355NM	अधिकतम शक्ति:	10W /15w/17W
पुनरावृत्ति आवृत्ति:	1-250kHz	स्थान सटीकता:	± 0.003 मिमी
पुनरावृत्ति परिशुद्धता:	±0.002मिमी	वर्कटेबल रेंज:	500 मिमी*500 मिमी
सीसीडी परिशुद्धता:	0.005मिमी	मैक्स वर्किंग रेंज:	460मिमी*460मिमी
XY गति:	50 मीटर/मिनट	स्थिति निर्धारण सटीकता:	±3um
मोटाई काटना:	<1 मिमी

वज़न:	3500 किलोग्राम
शक्ति:	10 किलोवाट
वोल्टेज:	220V, 380V
लेजर प्रकार:	यूवी
लेजर तरंगदैर्घ्य:	355NM
अधिकतम शक्ति:	10W /15w/17W
पुनरावृत्ति आवृत्ति:	1-250kHz
स्थान सटीकता:	± 0.003 मिमी
पुनरावृत्ति परिशुद्धता:	±0.002मिमी
वर्कटेबल रेंज:	500 मिमी*500 मिमी
सीसीडी परिशुद्धता:	0.005मिमी
मैक्स वर्किंग रेंज:	460मिमी*460मिमी
XY गति:	50 मीटर/मिनट
स्थिति निर्धारण सटीकता:	±3um
मोटाई काटना:	<1 मिमी

Shenzhen Stainless Steel Cutting Machine Wheel Made in China . CNC Laser Cutting Machine

YASTM-4C Stainless Steel Cutting Machine

YUSH Technology FPC ultraviolet laser cutting machine is designed for precision cutting of flexible circuit boards, CVL, RF, and thin plywood materials without requiring molds or protective plate fixation.

Applications

Available for flexible circuit boards and organic coating for precision cutting without mold or protective plate fixation. Using a high-energy laser source with precise beam control ensures improved processing speed and precise machining results.

Key Features

Proprietary control software with user-friendly interface, complete functionality, and simple operation
Capable of processing any graphics with synchronization for complete hierarchical cutting
Optimized optical system design ensures high beam quality and reduced focused spot size for precision
High-performance UV laser with optimal wavelength, beam quality, and peak power characteristics
Vacuum sample fixation eliminates need for mold protection plates, improving processing efficiency
Capable of cutting various substrate materials including silicon, ceramic, and glass
Automatic correction, positioning, multi-plate cutting, thickness measurement and compensation functions

Technical Specifications

Laser Source	Solid-state UV laser, 355nm wavelength
Laser Power	10W
Maximum Processing Format	610mm × 500mm (24" × 18")
XY Platform Maximum Speed	50m/min
Positioning Accuracy	±3μm
Repeatability	±1μm
System Precision	±20μm
Galvanometer Scanning Range	50mm × 50mm
Cutting Thickness	<1mm
Power Requirements	AC220V 50Hz/2.2KW; Three-phase 380V 50Hz/5.5KW
Air Requirements	516m³/h
Dimensions	1818mm × 2317mm × 1550mm
Operating Temperature	20℃ ±2℃
Humidity	<60% RH non-condensing

Additional Specifications

Maximum Board Length	610 × 500mm
Package Size	1818mm × 2317mm × 1550mm
Thickness	1mm
Power Supply	AC220V 50Hz/2.2KW; Three-phase 380V 50Hz/5.5KW
Working Air Pressure	516m³/h
Scope of Application	All V-CUT SMD PCB FPC board
